Intel Xeon E3-1268LV5 Prozessor 2,4 GHz 8 MB Smart Cache

Intel Xeon E3-1268LV5 Prozessor 2,4 GHz 8 MB Smart Cache

  • Marke: INTEL
  • Kategorie:
  • Lagerhaltungsnummer: CM8066201937901
  • EAN: 8592978258894 5054444098104 73 ...4098104 7330381810565mehr
Intel Xeon E3-1268LV5, Intel® Xeon® E3 v5, LGA 1151 (Socket H4), 14 nm, Intel, E3-1268LV5, 2,4 GHz

Handelspreise

Vertriebshändler Produkt Lagerhaltungsnummer Lagerbestand Aktualisiert Preis
Tech Data

Xeon E3-1268L v5 2.40 GHz FC-LGA14C Tray

 4674820 Kostenlos registrieren Lagerbestände einsehen

Beschreibung

Intel Xeon E3-1268LV5. Prozessorfamilie: Intel® Xeon® E3 v5, Prozessorsockel: LGA 1151 (Socket H4), Prozessor Lithografie: 14 nm. Speicherkanäle: Zweikanalig, Maximum internal memory supported by processor: 64 GB, Memory types supported by processor: DDR4-SDRAM, DDR3L-SDRAM. On-board Grafik Modell: Intel® HD Graphics P530, Maximum on-board graphics card memory: 64 GB, On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI. Market segment: Eingebettet, PCI Express сonfigurations: 1x16, 2x8, 1x8+2x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 3,4 GHz

Spezifikationen

Prozessor
Processor base frequency2,4 GHz
ProzessorherstellerIntel
Cooler includedNein
ProzessorfamilieIntel® Xeon® E3 v5
Anzahl der Prozessorkerne4
ProzessorsockelLGA 1151 (Socket H4)
Component forServer/Arbeitsstation
Prozessor Lithografie14 nm
BoxNein
Processor seriesIntel Xeon E3-1200 v5
ProzessorE3-1268LV5
Prozessor-Threads8
System-Bus8 GT/s
Memory bandwidth supported by processor (max)34,1 GB/s
Processor operating modes64-Bit
Processor ARK ID88178
Thermal Design Power (TDP)35 W
Processor cache typeSmart Cache
Processor cache8 MB
SteppingR0
Processor codenameSkylake
Prozessor-CodeSR2LQ
Max. Turbo-Taktfrequenz des Prozessor3,4 GHz
Bus typeDMI3
Speicher
Maximum internal memory supported by processor64 GB
Memory types supported by processorDDR4-SDRAM, DDR3L-SDRAM
Memory clock speeds supported by processor1333,1600,1866,2133 MHz
Memory bandwidth supported by processor (max)34,1 GB/s
Memory voltage supported by processor1,35 V
SpeicherkanäleZweikanalig
ECCJa
Grafik
On-board graphics adapterJa
On-board Grafik ModellIntel® HD Graphics P530
On-board graphics card outputs supportedEmbedded DisplayPort (eDP), DisplayPort, HDMI, DVI
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card 4K supportJa
On-board graphics card maximum resolution (HDMI)4096 x 2304 Pixel
Maximale Auflösung des On-Board Grafikadapters (DisplayPort)4096 x 2304 Pixel
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)4096 x 2304 Pixel
On-board graphics card refresh rate at maximum resolution (HDMI)24 Hz
Bildwiederholfrequenz des On-Board Grafikadapters bei maximaler Auflösung (DisplayPort)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)60 Hz
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.4
On-board graphics card ID0x191D
Energiemanagement
Thermal Design Power (TDP)35 W
Features
Thermal Monitoring TechnologiesJa
Idle StatesJa
Execute Disable BitJa
Maximum number of PCI Express lanes16
PCI Express slots version3.0
PCI Express сonfigurations1x16, 2x8, 1x8+2x4
Processor ARK ID88178
Thermal Design Power (TDP)35 W
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Processor package size37.5 x 37.5 mm
Scalability1S
Prozessor-CodeSR2LQ
On-board graphics card ID0x191D
Graphics & IMC lithography14 nm
Embedded options availableJa
CPU configuration (max)1
Market segmentEingebettet
Harmonized System (HS) code8542310001
Export Control Classification Number (ECCN)5A992C
Commodity Classification Automated Tracking System (CCATS)G077159
PCI Express CEM revision3.0
Prozessor Besonderheiten
Intel Wireless Display (WiDi) TechnologyJa
Intel® Turbo-Boost-Technologie2.0
Intel Trusted Execution TechnologyJa
Intel® Quick Sync Video TechnologyJa
Intel® InTru™-3D-TechnikJa
Intel® Insider™Ja
Intel Hyper-Threading TechnologyJa
Intel Clear Video HD TechnologyJa
Intel AES New InstructionsJa
Enhanced Intel SpeedStep TechnologieJa
Intel® Memory Protection Extensions (Intel® MPX)Ja
Intel® OS GuardJa
Intel VT-x with Extended Page Tables (EPT)Ja
Intel Virtualization Technology for Directed I/O (VT-d)Ja
Intel Virtualization Technology (VT-x)Ja
Intel TSX-NI version1,00
Intel TSX-NIJa
Intel Software Guard Extensions (Intel SGX)Ja
Intel Secure Key Technology version1,00
Intel® Secure KeyJa
Intel Enhanced Halt StateJa
Intel Clear Video Technology for MIDJa
Intel Clear Video TechnologyJa
Intel 64Ja
Conflict-Free processorJa
Intel® Boot GuardJa
Intel® vPro™ Platform EligibilityJa
Intel® Turbo Boost Technology 2.0 frequency3,4 GHz
Intel® Transactional Synchronization ExtensionsJa
Technical details
Supported memory typesDDR4-SDRAM, DDR3L-SDRAM
ProdukttypProcessor
Processor cache8192 KB
StatusLaunched
Processor brand nameIntel Xeon
Maximum resolution & refresh rate (VGA)N/A
Maximum resolution & refresh rate (Integrated Flat Panel)4096x2304@60Hz
Maximum resolution & refresh rate (HDMI)4096x2304@24Hz
Maximale Auflösung & Bildwiederholrate (DisplayPort)4096x2304@60Hz
Maximum memory64 GB
Market segmentEingebettet
Launch dateQ4'15
Last change63903513
Bus type unitsGT/s
Bus bandwidth8
Maximum resolution (WiDi)1080p
Product familyIntel Xeon Processor E3 v5 Family
Maximum graphics card memory64 GB
Processor ID0x191D
Bus speed8 GT/s
Servicing statusEnd of Servicing Lifetime
End of servicing updates dateFriday, September 30, 2022
Logistics data
Harmonized System (HS) code8542310001
Gewicht u. Abmessungen
Processor package size37.5 x 37.5 mm
Weitere Spezifikationen
Video-DecodierungJa
Maximaler Hauptspeicher64 GB
Maximaler Hauptspeicher65536 MB
Graphics outputeDP/DP/HDMI/DVI
