Beschreibung
Intel Core i9-14900K. Prozessorfamilie: Intel® Core™ i9, Prozessorsockel: LGA 1700, Prozessorhersteller: Intel. Speicherkanäle: Zweikanalig, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board Grafik Modell: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: Arbeitsstation, PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5,8 GHz, Intel® Thermal Velocity Boost Frequency: 6 GHz
Spezifikationen
| Prozessor | |
|---|---|
| Processor generation | Intel Core i9-14xxx |
| Prozessorhersteller | Intel |
| Prozessorfamilie | Intel® Core™ i9 |
| Anzahl der Prozessorkerne | 24 |
| Prozessorsockel | LGA 1700 |
| Box | Nein |
| Prozessor | i9-14900K |
| Prozessor-Threads | 32 |
| Memory bandwidth supported by processor (max) | 89,6 GB/s |
| Processor operating modes | 64-Bit |
| Processor ARK ID | 236773 |
| Processor cache type | Smart Cache |
| Processor cache | 36 MB |
| Stepping | B0 |
| Processor codename | Raptor Lake |
| Max. Turbo-Taktfrequenz des Prozessor | 6 GHz |
| Performance cores | 8 |
| Efficient cores | 16 |
| Performance-core boost frequency | 5,6 GHz |
| Performance-core base frequency | 3,2 GHz |
| Efficient-core boost frequency | 4,4 GHz |
| Efficient-core base frequency | 2,4 GHz |
| Processor base power | 125 W |
| Maximum turbo power | 253 W |
| Maximum number of DMI lanes | 8 |
| Speicher | |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
| Memory bandwidth supported by processor (max) | 89,6 GB/s |
| Speicherkanäle | Zweikanalig |
| Speicherbandbreite (max.) | 89,6 GB/s |
| ECC | Ja |
| Grafik | |
| Discrete graphics card | Nein |
| On-board graphics adapter | Ja |
| On-board Grafik Modell | Intel UHD Graphics 770 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1650 MHz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 Pixel |
| Maximale Auflösung des On-Board Grafikadapters (DisplayPort) | 7680 x 4320 Pixel |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 Pixel |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| Bildwiederholfrequenz des On-Board Grafikadapters bei maximaler Auflösung (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| Number of execution units | 32 |
| On-board graphics card ID | 0xA780 |
| Dediziertes Grafikmodell | Nicht verfügbar |
| Multi-Format Codec Engines | 2 |
| Features | |
| Thermal Monitoring Technologies | Ja |
| Idle States | Ja |
| Execute Disable Bit | Ja |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0, 5.0 |
| PCI Express сonfigurations | 1x16+1x4, 2x8+1x4 |
| Processor ARK ID | 236773 |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Processor package size | 45 x 37.5 mm |
| Thermal solution specification | PCG 2020A |
| Scalability | 1S |
| On-board graphics card ID | 0xA780 |
| Embedded options available | Nein |
| CPU configuration (max) | 1 |
| Market segment | Desktop |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Use conditions | Arbeitsstation, PC/Client/Tablet |
| Direct Media Interface (DMI) Revision | 4.0 |
| Prozessor Besonderheiten | |
| Intel® Turbo-Boost-Technologie | 2.0 |
| Intel® Quick Sync Video Technology | Ja |
| Intel Hyper-Threading Technology | Ja |
| Intel Clear Video HD Technology | Ja |
| Intel AES New Instructions | Ja |
| Enhanced Intel SpeedStep Technologie | Ja |
| Intel Turbo Boost Max Technology 3.0 | Ja |
| Intel® Speed Shift Technology | Ja |
| Intel® OS Guard | Ja |
| Intel VT-x with Extended Page Tables (EPT) | Ja |
| Intel Virtualization Technology for Directed I/O (VT-d) | Ja |
| Intel Virtualization Technology (VT-x) | Ja |
| Intel® Secure Key | Ja |
| Intel 64 | Ja |
| Intel® Boot Guard | Ja |
| Intel® Thermal Velocity Boost | Ja |
| Intel® Volume Management Device (VMD) | Ja |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Ja |
| Mode-based Execute Control (MBE) | Ja |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5,8 GHz |
| Intel® Thermal Velocity Boost Frequency | 6 GHz |
| Intel® Control-flow Enforcement Technology (CET) | Ja |
| Intel® Thread Director | Ja |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Ja |
| Intel® Standard Manageability (ISM) | Ja |
| Intel® Adaptive Boost Technology | Ja |
| Betriebsbedingungen | |
| Tjunction | 100 °C |
| Technical details | |
| Status | Launched |
| Market segment | Desktop |
| Launch date | Q4'23 |
| OpenCL version | 3.0 |
| Verpacken | |
| Verpackungsart | Einschub |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Gewicht u. Abmessungen | |
| Processor package size | 45 x 37.5 mm |
| Weitere Spezifikationen | |
| Maximaler Hauptspeicher | 192 GB |
| Pufferspeicher L2 | 32768 KB |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
