Intel Core i7-7700 Prozessor 3,6 GHz 8 MB Smart Cache

Intel Core i7-7700 Prozessor 3,6 GHz 8 MB Smart Cache

  • Marke: INTEL
  • Kategorie:
  • Lagerhaltungsnummer: CM8067702868314
  • EAN: 8592978063016 5415247283683 57 ...7283683 5706998537065 0675901427791mehr
Intel Core i7-7700, Intel® Core™ i7, LGA 1151 (Socket H4), 14 nm, Intel, i7-7700, 3,6 GHz

Handelspreise

Vertriebshändler Produkt Lagerhaltungsnummer Lagerbestand Aktualisiert Preis
Tech Data

CPU/Core i7-7700 3.60GHz LGA1151 TRAY

 4043822 Kostenlos registrieren Lagerbestände einsehen

Beschreibung

Intel Core i7-7700. Prozessorfamilie: Intel® Core™ i7, Prozessorsockel: LGA 1151 (Socket H4), Prozessor Lithografie: 14 nm. Speicherkanäle: Zweikanalig, Maximum internal memory supported by processor: 64 GB, Memory types supported by processor: DDR4-SDRAM, DDR3L-SDRAM. On-board Grafik Modell: Intel® HD Graphics 630, Maximum on-board graphics card memory: 64 GB, On-board graphics card outputs supported: DisplayPort, Embedded DisplayPort (eDP), HDMI. Market segment: Desktop, PCI Express сonfigurations: 1x16, 2x8, 1x8+2x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 4,2 GHz

Spezifikationen

Prozessor
Processor generationIntel® Core™ i7 der siebten Generation
Processor base frequency3,6 GHz
ProzessorherstellerIntel
Cooler includedNein
ProzessorfamilieIntel® Core™ i7
Anzahl der Prozessorkerne4
ProzessorsockelLGA 1151 (Socket H4)
Component forPC
Prozessor Lithografie14 nm
BoxNein
Prozessori7-7700
Prozessor-Threads8
System-Bus8 GT/s
Processor operating modes64-Bit
Processor ARK ID97128
Thermal Design Power (TDP)65 W
Processor cache typeSmart Cache
Processor cache8 MB
SteppingB0
Processor codenameKaby Lake
Prozessor-CodeSR338
Max. Turbo-Taktfrequenz des Prozessor4,2 GHz
Number of QPI links0
Bus typeDMI3
Generation7th Generation
Speicher
Maximum internal memory supported by processor64 GB
Memory types supported by processorDDR4-SDRAM, DDR3L-SDRAM
Memory clock speeds supported by processor1333,1600,2133,2400 MHz
Memory voltage supported by processor1,35 V
SpeicherkanäleZweikanalig
ECCNein
Grafik
On-board graphics adapterJa
On-board Grafik ModellIntel® HD Graphics 630
On-board graphics card outputs supportedDisplayPort, Embedded DisplayPort (eDP), HDMI
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1150 MHz
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card 4K supportJa
On-board graphics card maximum resolution (HDMI)4096 x 2304 Pixel
Maximale Auflösung des On-Board Grafikadapters (DisplayPort)4096 x 2304 Pixel
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)4096 x 2304 Pixel
On-board graphics card refresh rate at maximum resolution (HDMI)24 Hz
Bildwiederholfrequenz des On-Board Grafikadapters bei maximaler Auflösung (DisplayPort)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)60 Hz
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
On-board graphics card ID0x5912
Energiemanagement
Thermal Design Power (TDP)65 W
Features
Thermal Monitoring TechnologiesJa
Idle StatesJa
Execute Disable BitJa
Maximum number of PCI Express lanes16
PCI Express slots version3.0
PCI Express сonfigurations1x16, 2x8, 1x8+2x4
Processor ARK ID97128
Thermal Design Power (TDP)65 W
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Processor package size37.5 x 37.5 mm
Thermal solution specificationPCG 2015C
Scalability1S
Prozessor-CodeSR338
On-board graphics card ID0x5912
Embedded options availableJa
CPU configuration (max)1
Market segmentDesktop
Harmonized System (HS) code85423119
Export Control Classification Number (ECCN)5A992C
Commodity Classification Automated Tracking System (CCATS)G077159
PCI Express CEM revision3.0
Prozessor Besonderheiten
Intel® Turbo-Boost-Technologie2.0
Intel Trusted Execution TechnologyJa
Intel® Quick Sync Video TechnologyJa
Intel® InTru™-3D-TechnikJa
Intel Identity Protection TechnologyJa
Intel Hyper-Threading TechnologyJa
Intel Clear Video HD TechnologyJa
Intel AES New InstructionsJa
Enhanced Intel SpeedStep TechnologieJa
Intel® Memory Protection Extensions (Intel® MPX)Ja
Intel® Optane™ Memory ReadyJa
Intel® OS GuardJa
Intel VT-x with Extended Page Tables (EPT)Ja
Intel Virtualization Technology for Directed I/O (VT-d)Ja
Intel Virtualization Technology (VT-x)Ja
Intel TSX-NI version1,00
Intel TSX-NIJa
Intel Stable Image Platform Program (SIPP) version1,00
Intel Stable Image Platform Program (SIPP)Ja
Intel Software Guard Extensions (Intel SGX)Ja
Intel Secure Key Technology version1,00
Intel® Secure KeyJa
Intel Identity Protection Technology version1,00
Intel Enhanced Halt StateJa
Intel Clear Video Technology for MIDJa
Intel Clear Video TechnologyJa
Intel 64Ja
Conflict-Free processorJa
Intel® Boot GuardJa
Intel® vPro™ Platform EligibilityJa
Intel® Turbo Boost Technology 2.0 frequency4,2 GHz
Intel® Transactional Synchronization ExtensionsJa
Betriebsbedingungen
Tjunction100 °C
Technical details
Supported memory typesDDR4-SDRAM, DDR3L-SDRAM
ProdukttypProcessor
Processor cache8192 KB
StatusLaunched
Processor brand name7th Gen Intel Core i7 processors
Maximum resolution & refresh rate (Integrated Flat Panel)4096x2304@60Hz
Maximum resolution & refresh rate (HDMI)4096x2304@24Hz
Maximale Auflösung & Bildwiederholrate (DisplayPort)4096x2304@60Hz
Maximum memory64 GB
Market segmentDesktop
Launch dateQ1'17
Last change63903513
Bus type unitsGT/s
Bus bandwidth8
Product family7th Generation Intel Core i7 Processors
Maximum graphics card memory64 GB
Processor ID0x5912
Bus speed8 GT/s
Verpacken
VerpackungsartEinzelhandels-Box
Logistics data
Harmonized System (HS) code85423119
Gewicht u. Abmessungen
Processor package size37.5 x 37.5 mm
Weitere Spezifikationen
Video-DecodierungJa
Maximaler Hauptspeicher64 GB
Maximaler Hauptspeicher65536 MB
