Intel Celeron N3350 Prozessor 1,1 GHz 2 MB L2
- Marke: INTEL
- Kategorie:
- Lagerhaltungsnummer: FH8066802980002
- EAN: 8592978407926
Intel Celeron N3350, Intel® Celeron®, BGA 1296, 14 nm, Intel, N3350, 1,1 GHz
Offer details
Handelspreise
| Vertriebshändler | Produkt | Lagerhaltungsnummer | Lagerbestand | Aktualisiert | Preis |
|---|---|---|---|---|---|
|
N3350 2M Cache up to 2.40 GHz |
4557370 |
Beschreibung
Intel Celeron N3350. Prozessorfamilie: Intel® Celeron®, Prozessorsockel: BGA 1296, Prozessor Lithografie: 14 nm. Speicherkanäle: Zweikanalig, Maximum internal memory supported by processor: 8 GB, Memory types supported by processor: DDR3L-SDRAM, LPDDR3-SDRAM, LPDDR4-SDRAM. On-board Grafik Modell: Intel® HD Graphics 500, Maximum on-board graphics card memory: 8 GB, On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, MIPI-DSI. Market segment: Mobil, Use conditions: PC/Client/Tablet, PCI Express сonfigurations: 1x4+1x2, 4x1, 2x1+1x2+1x2. USB Version: 2.0/3.2 Gen 1 (3.1 Gen 1)
Spezifikationen
| Prozessor | |
|---|---|
| Processor base frequency | 1,1 GHz |
| Prozessorhersteller | Intel |
| Cooler included | Nein |
| Prozessorfamilie | Intel® Celeron® |
| Anzahl der Prozessorkerne | 2 |
| Prozessorsockel | BGA 1296 |
| Prozessor Lithografie | 14 nm |
| Box | Nein |
| Processor series | Intel Celeron N3000 series |
| Prozessor | N3350 |
| Prozessor-Threads | 2 |
| System-Bus | 5 GT/s |
| Processor operating modes | 64-Bit |
| Processor ARK ID | 95598 |
| Thermal Design Power (TDP) | 6 W |
| Processor cache type | L2 |
| Processor cache | 2 MB |
| Scenario Design Power (SDP) | 4 W |
| Processor codename | Apollo Lake |
| Max. Turbo-Taktfrequenz des Prozessor | 2,4 GHz |
| Speicher | |
| Maximum internal memory supported by processor | 8 GB |
| Memory types supported by processor | DDR3L-SDRAM, LPDDR3-SDRAM, LPDDR4-SDRAM |
| Memory clock speeds supported by processor | 1866,2400 MHz |
| Speicherkanäle | Zweikanalig |
| ECC | Nein |
| Grafik | |
| On-board graphics adapter | Ja |
| On-board Grafik Modell | Intel® HD Graphics 500 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP), DisplayPort, HDMI, MIPI-DSI |
| On-board graphics card base frequency | 200 MHz |
| On-board graphics card burst frequency | 650 MHz |
| On-board graphics card dynamic frequency (max) | 650 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Number of displays supported (on-board graphics) | 3 |
| Number of execution units | 12 |
| On-board graphics card ID | 0x5A85 |
| Energiemanagement | |
| Thermal Design Power (TDP) | 6 W |
| Scenario Design Power (SDP) | 4 W |
| Features | |
| Thermal Monitoring Technologies | Ja |
| Idle States | Ja |
| Execute Disable Bit | Ja |
| Maximum number of PCI Express lanes | 6 |
| PCI Express slots version | 2.0 |
| PCI Express сonfigurations | 1x4+1x2, 4x1, 2x1+1x2+1x2 |
| Processor ARK ID | 95598 |
| Thermal Design Power (TDP) | 6 W |
| Processor package size | 24mm x 31mm |
| On-board graphics card ID | 0x5A85 |
| Embedded options available | Ja |
| CPU configuration (max) | 1 |
| Market segment | Mobil |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) | G154294 |
| PCI Express CEM revision | 2.0 |
| Use conditions | PC/Client/Tablet |
| I/O configuration | |
| USB Version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Anzahl der USB-Anschlüsse | 8 |
| Total number of SATA connectors | 2 |
| Number of SATA III connectors | 2 |
| Integrated LAN | Nein |
| General Purpose IO | Yes |
| UART | Ja |
| Prozessor Besonderheiten | |
| Intel Wireless Display (WiDi) Technology | Nein |
| Intel® Turbo-Boost-Technologie | Nein |
| Intel Trusted Execution Technology | Nein |
| Intel® Smart-Response-Technologie | Nein |
| Intel Smart Connect Technology | Nein |
| Intel® Quick Sync Video Technology | Ja |
| Intel® InTru™-3D-Technik | Nein |
| Intel® Insider™ | Nein |
| Intel Identity Protection Technology | Ja |
| Intel Hyper-Threading Technology | Nein |
| Intel Clear Video HD Technology | Ja |
| Intel Anti-Theft Technology | Nein |
| Intel AES New Instructions | Ja |
| Enhanced Intel SpeedStep Technologie | Ja |
| Intel® Memory Protection Extensions (Intel® MPX) | Ja |
| Intel® OS Guard | Ja |
| Intel VT-x with Extended Page Tables (EPT) | Ja |
| Intel Virtualization Technology for Directed I/O (VT-d) | Ja |
| Intel Virtualization Technology (VT-x) | Ja |
| Intel Stable Image Platform Program (SIPP) version | 0,00 |
| Intel Stable Image Platform Program (SIPP) | Nein |
| Intel Smart Response Technology version | 0,00 |
| Intel Smart Idle Technology | Nein |
| Intel Smart Connect Technology version | 0,00 |
| Intel Small Business Advantage (SBA) version | 0,00 |
| Intel® Small Business Advantage (Intel® SBA) | Nein |
| Intel Secure Key Technology version | 1,00 |
| Intel® Secure Key | Ja |
| Intel Secure Boot Technology version | 1,00 |
| Intel Secure Boot | Ja |
| Intel Rapid Storage Technology | Nein |
| Intel Identity Protection Technology version | 1,00 |
| Intel HD Audio Technology | Ja |
| Intel Enhanced Halt State | Ja |
| Intel Clear Video Technology for MID | Ja |
| Intel Clear Video Technology | Ja |
| Intel 64 | Ja |
| Conflict-Free processor | Ja |
| Intel® vPro™ Platform Eligibility | Nein |
| Intel Virtualization Technology for Itanium (VT-i) | Nein |
| Betriebsbedingungen | |
| Tjunction | 105 °C |
| Technical details | |
| Supported memory types | DDR3L-SDRAM, LPDDR3-SDRAM |
| Produkttyp | System on Chip |
| Processor cache | 2048 KB |
| Status | Launched |
| Processor brand name | Intel Celeron |
| OpenGL support | Ja |
| Maximum memory | 8 GB |
| Market segment | Mobil |
| Launch date | Q3'16 |
| Last change | 63903513 |
| Product family | Intel Celeron Processor |
| Maximum graphics card memory | 8 GB |
| Processor ID | 0x5A85 |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Gewicht u. Abmessungen | |
| Processor package size | 24mm x 31mm |
| Weitere Spezifikationen | |
| Video-Decodierung | Ja |
| Maximaler Hauptspeicher | 8 GB |
| Maximaler Hauptspeicher | 8192 MB |
| Graphics output | eDP/DP/HDMI/MIPI-DSI |
